MUVP type couplings

COUPLINGS TYPE MUVP

Elastic-bushed stud clutches (MUVP) are simple and, respectively, cheap type of couplings. However, their use is limited due to low compensating properties., relatively high loads on the connected shafts, limited resource elastomer bushings, impossibility of explosive use- fire hazardous areas.

MUVP "NTK" are produced in accordance with GOST 21424-93 with steel half couplings. Compensating ring material - oil-resistant rubber compound based on nitrile rubbers 3826 ТУ380051166-98 (TU U 600152135.040-96) by default or other according to the customer's order. Delivery of standard couplings "for boring" - from the warehouse of the enterprise. Delivery with bored to size half couplings and made keyways - according to the "Questionnaire" filled in by the Customer.

MUVP11
MUVP12
MUVP11
MUVP12
previous arrow
next arrow

SPECIFICATIONS

Designation Mcr D, mm d1 max, mm d2 max, mm L, mm l, mm with, PC D1, mm
MUVP 6,3 6,3 67 22 11 48 22 3 19
MUVP 16 16 75 28 16 83 40 4 19
MUVP 31,5 31,5 90 32 18 84 40 4 19
MUVP 63 63 100 42 24 104 50 6 19
MUVP 125 125 120 55 30 125 60 4 27
MUVP 250 250 140 65 45 165 80 8 27
MUVP 500 500 170 70 45 226 110 6 35
MUVP 710 710 185 75 56 226 110 8 35
MUVP 1000 1000 190 75 70 286 140 10 35
MUVP 2000 2000 240 110 90 288 140 10 45
MUVP 4000 4000 300 130 95 350 170 10 56,5
MUVP 8000 8000 360 140 125 432 210 10 70,5
MUVP 16000 16000 450 180 160 515 250 10 86,5
